Tosot TW09HQ1C8D User Manual

4
Technical Information
Service Manual
2. Specications
2.1 Specication Sheet
Model TW09HQ1C8D
Product Code CB456000400_L59684
Power Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) Btu/h 9000(3100~9600)
Heating Capacity(Min~Max) Btu/h 9500(3100~12000)
Cooling Power Input(Min~Max) W 900(375~1300)
Heating Power Input(Min~Max) W 800(300~1350)
Cooling Power Current A 4
Heating Power Current A 3.6
Rated Input W 1350
Rated Current A 6.0
Air Flow Volume(SH/H/M/L) CFM 318/288/241/171
Dehumidifying Volume Pint/h 1.69
EER (Btu/h)/W 10.00
COP (Btu/h)/W 11.88
SEER 16.00
HSPF 9.00
Application Area yd
2
14.35-21.53
Indoor Unit
Model of indoor unit TW09HQ1C8D/I
Indoor Unit Product Code CB456N00400_L59684
Fan Type Cross-ow
Diameter Length(DXL) inch Φ3 7/8X22 13/16
Fan Motor Cooling Speed(SH/H/M/L) r/min 1350/1200/1050/750
Fan Motor Heating Speed(SH/H/M/L) r/min 1350/1200/1050/850
Output of Fan Motor W 20
Fan Motor RLA A 0.2
Fan Motor Capacitor μF 1
Evaporator Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ3/16
Row-n Gap inch 2-1/16
Coil Length (LXDXW) inch 23X7/8X10 1/2
Swing Motor Model MP24AA
Output of Swing Motor W 1.5
Fuse A 3.15
Sound Pressure Level(SH/H/M/L) dB (A) 43/38/34/28
Sound Power Level(SH/H/M/L) dB (A) 53/48/44/38
Dimension (WXHXD) inch 31 1/8X10 7/8X7 7/8
Dimension of Carton Box (LXWXH) inch 34X10 9/16X13 7/8
Dimension of Package (LXWXH) inch 34X10 11/16X14 7/16
Net Weight Ib 19.8
Gross Weight Ib 24.3

Tosot TW09HQ1C8D Specifications

General

Brand	Tosot
Model	TW09HQ1C8D
Category	Air Conditioner
Language	English
