5
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit TW09HQ1C8D/O
Outdoor Unit Product Code CB427W02200_L59684
Compressor Manufacturer/Trademark ZHUHAI GREE DAIKIN DEVICE CO.,LTD
Compressor Model 1GDY23AXD
Compressor Oil DAPHNE FVC50K
Compressor Type Swing
Compressor Locked Rotor Amp (L.R.A) A /
Compressor RLA A 6.6
Compressor Power Input W 845
Overload Protector KSD115
℃
or HPC115/95
Throttling Method Capillary
Operation temp ºF 60.8~86
Ambient temp (cooling) ºF 0~115
Ambient temp (heating) ºF -4~75
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter inch Φ5/16
Rows-n Gap inch 1-1/16
Coil Length (LXDXW) inch 28X3/4X20
Fan Motor Speed rpm 820
Output of Fan Motor W 30
Fan Motor RLA A 0.37
Fan Motor Capacitor μF 2.5
Air Flow Volume of Outdoor Unit CFM 942
Fan Type Axial-ow
Fan Diameter inch Φ15 3/4
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
PSIG 620
Permissible Excessive Operating
Pressure for the Suction Side
PSIG 360
Sound Pressure Level (H/M/L) dB (A) 52/-/-
Sound Power Level (H/M/L) dB (A) 62/-/-
Dimension (WXHXD) inch 30 9/16X21 1/4X12 5/8
Dimension of Carton Box (LXWXH) inch 33 3/8X14 3/16X22 13/16
Dimension of Package (LXWXH) inch 33 1/2X14 5/16X23 7/16
Net Weight Ib 65.0
Gross Weight Ib 70.6
Refrigerant R410A
Refrigerant Charge oz 24.7
Connection
Pipe
Length ft 24.6
Gas Additional Charge oz/ft 0.2
Outer Diameter Liquid Pipe inch Φ1/4
Outer Diameter Gas Pipe inch Φ3/8
Max Distance Height ft 32.8
Max Distance Length ft 49.2
Note:The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
