118
Installation and Maintenance
Service Manual
NO.
Description
Qty
TW12HQ2C2DI
Product Code CB439N05601_X18545
1 Front Panel 27230006884 1
2 Display Board 30565281 1
3 Front Case Assy 00000200045 1
4 Helicoid Tongue 26112436 1
5 Left Axile Bush 10512037 1
6 Rear Case assy 00000100093 1
7 Drainage Hose 05230014 1
8 Ring of Bearing 26152022 1
9 O-Gasket sub-assy of Bearing 76512051 1
10 Evaporator Support 24212174 1
11 Cold Plasma Generator / 0
12 Evaporator Assy 0100200003001 1
13 Wall Mounting Frame 01252484 1
14 Cross Flow Fan 10352056 1
15 Fan Motor 150104060029 1
16 Connecting pipe clamp 2611216401 1
17 Rubber Plug (Water Tray) 76712012 1
18 SteppingMotor 1521210710 1
19 Crank 73012005 1
20 Electric Box Assy 100002003834 1
21 Axile Bush 10542036 1
22 Terminal Board 42011233 1
23 Jumper 4202021920 1
24 Main Board 30138001018 1
25 Electric Box Cover Sub-Assy 0140206501 1
26 Shield Cover of Electric Box Cover 01592150 1
27 Electric Box Cover 2011220701 1
28 Power Cord / 0
29 Connecting Cable / 0
30 Connecting Cable / 0
31 Remote Controller 305001000085_TOSOT 1
32 Test Board Assy / 0
33 Guide Louver 1051293101 1
34 Air Louver 1 10512723 1
Above data is subject to change without notice.
