Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
TW18HQ2C2DI
Product Code CB439N05901_X18545
1 Decorative Strip(Left) / 0
2 Front Panel 27230006886 1
3 Display Board 30565278 1
4 Filter Sub-Assy 1112208904 2
5 Decorative Board (Left and Right) 20192662 1
6 Front Case Assy 00000200042 1
7 Guide Louver 1051276501 1
8 Axile Bush 10542036 2
9 Air Louver(Manual) 10512732 3
10 Helicoid Tongue 26112512 1
11 Left Axile Bush 10512037 1
12 Rear Case assy 22202571 1
13 Rubber Plug (Water Tray) 76712012 1
14 O-Gasket sub-assy of Bearing 76512051 1
15 Ring of Bearing 26152025 1
16 Evaporator Support 24212177 1
17 Evaporator Assy 01100100085 1
18 Cross Flow Fan 10352060 1
19 Fan Motor 15012136 1
20 Motor Press Plate 26112511 1
21 Wall Mounting Frame 01362026 1
22 Connecting pipe clamp 2611218801 1
23 Crank 73012005 1
24 Stepping Motor 1521240212 1
25 Drainage Hose 05230014 1
26 Electric Box Assy 100002003815 1
27 Lower Shield of Electric Box 01592139 1
28 Electric Box 2011221105 1
29 Jumper 4202021924 1
30 Main Board 30138001018 1
31 Shield Cover of Electric Box 01592176 1
32 Electric Box Cover 2011220901
1
33 Terminal Board 42011233 1
34 Decorative Board (Right) / 0
35 Screw Cover 2425201726 3
36 Electric Box Cover2 2011221001 1
37 Power Cord / 0
38 Connecting Cable / 0
39 Connecting Cable / 0
40 Remote Controller 305001000085_TOSOT 1
41 Cold Plasma Generator / 0
Above data is subject to change without notice.
