122
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
TW24HQ2C2DI
Product Code CB439N05701_X18545
1 Front Panel 27230006887 1
2 Filter Sub-Assy 11012007 2
3 Screw Cover 2425245301 3
4 Front Case Assy 00000200057 1
5 Air Louver(Manual) 10512737 3
6 Helicoid Tongue sub-assy 26112382 1
7 Left Axile Bush 10512037 1
8 Rear Case assy 22202570 1
9 Rubber Plug (Water Tray) 76712012 1
10 Ring of Bearing 26152025 1
11 O-Gasket sub-assy of Bearing 76512051 1
12 Cross Flow Fan 10352057 1
13 Evaporator Support 24212178 1
14 Evaporator Assy 01100100029 1
15 Cold Plasma Generator / 0
16 Wall Mounting Frame 01252229 1
17 Motor Press Plate 26112515 1
18 Fan Motor 15012136 1
19 Connecting pipe clamp 26112514 1
20 Drainage Hose 0523001405 1
21 Stepping Motor 1521240212 1
22 Crank 73012005 1
23 Guide Louver 1051232001 1
24 Axile Bush 10542036 2
25 Electric Box 2011221105 1
26 Terminal Board 42011233 1
27 Electric Box Cover2 2011221001 1
28 Main Board 30138001018 1
29 Display Board 30565278 1
30 Shield Cover of Electric Box 01592176 1
31 Electric Box Cover 2011220901 1
32 Jumper 4202021926
1
33 Lower Shield of Electric Box 01592139 1
34 Electric Box Assy 100002003844 1
35 Power Cord / 0
36 Connecting Cable / 0
37 Connecting Cable / 0
38 Temperature Sensor 3900031302 1
39 Remote Controller 305001000085_TOSOT 1
Above data is subject to change without notice.
