124
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW09HQ1C8D/O
Product Code CB427W02200_L59684
1 Front Grill 01473012 1
2 Front Panel Assy 0153304804 1
3 Axial Flow Fan 10333004 1
4 Chassis Sub-assy 01700000095P 1
5 Clapboard Sub-Assy 0123338502 1
6 Drainage Connecter 06123401 1
7 Compressor Gasket 76713027 3
8 4-Way Valve Assy 03073369 1
9 Valve Support 0171314201P 1
10 Cut off Valve 071302391 1
11 Valve 07100003 1
12 Valve Support Block 26113017 2
13 Right Side Plate Assy 013030713 1
14 Big Handle / 0
15 Magnet Coil 4300040050 1
16 Electric Expand Valve Fitting / 0
17 Rear Grill 01473009 1
18 Electric Box Sub-Assy 10000500131 1
19 Filter Board / 0
20 Main Board 30138000679 1
21 Reactor 43130184 1
22 Electric Box Assy 10000100292 1
23 Terminal Board 422000060016 1
24 Wire Clamp 71010003 2
25 Top Cover Sub-Assy 000051060006 1
26 Condenser Assy 01100200349 1
27 Motor Support 01703104 1
28 Fan Motor 1501306723 1
29 Compressor Overload Protector(External) 00183111 1
30 Compressor and Fittings 00103892 1
31 Small Handle 26233100 1
32 Temperature Sensor 3900030805
1
To Next Page
