138
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Qty
TW12CQ2B8DO
Product Code CB419W04400_L91250
1 Front Grill 01473012 1
2 Front Panel Assy 0153501604 1
3 Axial Flow Fan 10333004 1
4 Fan Motor 1501308507 1
5 Chassis Sub-assy 017000000181P 1
6 Electrical Heater(Compressor) 76513004 1
7 Compressor and Fittings 00103892 1
8 Compressor Gasket 76713027 3
9 Reactor 43130185 1
10 Valve Support 01713041 1
11 Valve 07100006 1
12 Valve 07100003 1
13 Valve Cover 22243010 1
14 Cable Cross Plate 1 02123013P 1
15 Cable Cross Plate 2 02123014P 1
16 Right Side Plate Sub-Assy 00013000001002 1
17 4-Way Valve Assy / 0
18 Magnet Coil / 0
19 Electric Expansion Valve Sub-Assy 030026000070 1
20 Electric Expand Valve Fitting 07200200001205 1
21 Rear Grill 01475014 1
22 Condenser Assy 011002000140 1
23 Compressor Overload Protector(External) 00183111 1
24 Clapboard Sub-Assy 01233090 1
25 Top Cover Sub-Assy 00005106001201 1
26 Motor Suport Spot Welding Sub-assy / 0
27 Electric Box Cover Sub-Assy 0260309601 1
28 Magnetic Ring 49010104 1
29 Main Board 30138000520 1
30 Radiator 49013026 1
31 Electric Box 1 20113005 1
32 Terminal Board 422000060016 1
33 Wire Clamp 71010003 2
34 Electric Box Assy 10000100189 1
35 Temperature Sensor 39000310 1
To Next Page
