140
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW09HQ2C2DO
Product Code CB419W04300_X18545
1 Front Grill 01473012 1
2 Front Panel Assy 0153304901 1
3 Axial Flow Fan 10333004 1
4 Electrical Heater (Chassis) 76510004 1
5 Chassis Sub-assy 01700000053P 1
6 Drainage Connecter 06123401 1
7 Electrical Heater(Compressor) 76513004 1
8 Compressor and Fittings 00103892 1
9 Compressor Gasket 76713027 3
10 Magnet Coil 4300040047 1
11 Valve Support 01713041 1
12 Valve 07100005 1
13 Valve 07100003 1
14 Big Handle / 0
15 Right Side Plate 0130306903 1
16 4-Way Valve Assy 03073083 1
17 4-Way Valve 430004032 1
18 Electric Expansion Valve Sub-Assy 07133769 1
19 Electric Expand Valve Fitting 07200200001204 1
20 Rear Grill 01473057 1
21 Condenser Assy 01163565 1
22 Compressor Overload Protector(External) 00183111 1
23 Clapboard Sub-Assy 01233034 1
24 Top Cover Sub-Assy 00005106001201 1
25 Motor Support 0170310201 1
26 Fan Motor 1501308507 1
27 Electric Box Cover Sub-Assy 0260309601 1
28 Main Board 30138000521 1
29 Radiator 49013026 1
30 Electric Box 1 20113005 1
31 Terminal Board 422000060016 1
32 Wire Clamp 71010003
2
33 Electric Box Assy 10000100188 1
34 Temperature Sensor 3900030903 1
35 Drainage hole Cap 76713018 1
36 Drainage hole Cap 7671301804 1
