Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW18HQ2C2DO
Product Code CB419W06700_X18545
1 Front Grill 016004000006 1
2 Front Panel Assy 000003060055 1
3 Axial Flow Fan 10335008 1
4 Drainage Plug / 0
5 Chassis Sub-assy 01700000161P 1
6 Drainage Connecter 06123401 1
7 Compressor and Fittings 00105249G 1
8 4-Way Valve 430004032 1
9 4-Way Valve Assy 03073411 1
10 Capillary Tube 03015737 1
11 Cut off Valve 07130239 1
12 Right Side Plate Assy 0130329208 1
13 Valve Support Sub-Assy 01705046P 1
14 Cut off Valve 07133844 1
15 Handle 26233053 1
16 Capacitor CBB65 / 0
17 Temperature Sensor 3900030902 1
18 Wiring clamp / 0
19 Rear Grill 01475020 1
20 Condenser Assy 01103000090 1
21 Clapboard Sub-Assy 01235081 1
22 Condenser Support Plate 01795031 1
23 Motor Support Sub-Assy 01705067 1
24 Coping Sub-Assy 000051000017 1
25 Left Side Plate 01305093P 1
26 left handle / 0
27 Terminal Board 42200006001401 1
28 Electric Box Assy 10000100632 1
29 Electric Box Cover 20125002 1
30 Main Board 30138000873 1
31 Radiator 4901521502 1
32 Electric Box 20115003
1
33 Capacitor CBB61 / 0
34 Electric box (reproong) / 0
35 Fan Motor 1501506402 1
