Tosot TW09HQ1C8D User Manual

146
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
TW24HQ2C2DO
Product Code CB419W03600_X18545
1 Front Grill 016004060005 1
2 Brushless DC Motor 15010400000102 1
3 Electric Box (Fireproong) 01413426 1
4 Radiator 49015215 1
5 Main Board 30138000504 1
6 Electric Box Assy 10000100164 1
7 Terminal Board Support sub-assy 01703209 1
8 Terminal Board 42200006001401 1
9 Left Handle / 0
10 Left Side Plate 01305043P 1
11 Coping 01255020P 1
12 Motor Support Sub-Assy 017012000017 1
13 Condenser Support Plate 01175092 1
14 Clapboard Sub-Assy 01235040 1
15 Condenser Assy 01100200162 1
16 Rear Grill 01475013 1
17 Wiring Clamp 26115004 1
18 Temperature Sensor 3900030901 1
19 Capacitor CBB65 / 0
20 Right Side Plate 0130504402P 1
21 Big Handle 02115005 1
22 Cut off Valve 07133157 1
23 Valve Support Sub-Assy 0171501201P 1
24 Bafe (valve support) / 0
25 Capillary Tube 03015737 1
26 4-Way Valve Assy 03015200087 1
27 Magnet Coil 4300040045 1
28 Compressor Gasket 76713066 3
29 Compressor and Fittings 0010505701 1
30 Drainage Connecter 06123401 1
31 Chassis Sub-assy 0280319604P 1
32 Drainage Plug /
0
33 Axial Flow Fan 10335014 1
34 Front Side Plate Sub-Assy 01303249P 1
35 Front Panel Assy 0153501405 1

Tosot TW09HQ1C8D Specifications

General

Brand	Tosot
Model	TW09HQ1C8D
Category	Air Conditioner
Language	English
