Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWC12AGCXD-A3DNA1A/O
TW12HXP2A1AO
Outdoor Unit Product Code CB385W16500 CB385W16700
Compressor Manufacturer
Shanghai Highly Electrical
Appliances Co.,Ltd.
Shanghai Highly Electrical
Appliances Co.,Ltd.
Compressor Model GSD098XKUA7JL6B GSD098XKUA7JL6B
Compressor Oil
ACS-68R or equiva le nt
320±20ml
ACS-68R or equiva le nt
320±20ml
Compressor Type Rotary Rotary
Compressor LRA. A / /
Compressor RLA A 15 15
Compressor Power Input W 784 784
Compressor Overload Protector / /
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature Range ºF -4~122 -4~122
Heating Operation Ambient Temperature Range ºF / -22~86
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94 Φ7.94
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 761.5×38.1×528 761.5×38.1×528
Fan Motor Speed rpm 900 900
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 1294.7 1294.7
Fan Type Cross-ow Cross-ow
Fan Diameter mm Φ420 Φ420
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 52 52
Sound Power Level dB (A) 62 62
Dimension (WXHXD) inch 31 37/64 × 21 27/32 × 13 25/32 31 37/64 × 21 27/32 × 13 25/32
Dimension of Carton Box (LXWXH) inch
34 7/32 × 15 35/64 × 23 25/64 34 7/32 × 15 35/64 × 23 25/64
Dimension of Package (LXWXH) inch 34 21/64 × 15 43/64 × 24 13/32 34 21/64 × 15 43/64 × 24 13/32
Net Weight Ib 70.6 73.9
Gross Weight Ib 76.1 79.4
Refrigerant R410A R410A
Refrigerant Charge oz 42.3 42.3
Connection
Pipe
Connection Pipe Length ft 16.4 16.4
Connection Pipe Gas Additional Charge oz/ft 0.161 0.215
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 1/2 1/2
Max Distance Height ft 32.8 32.8
Max Distance Length ft 65.6 65.6
Note: The connection pipe applies metric diameter.
