Technical Information
Service Manual
Model GWC09AGCXD-A3DNA1A
GWH09AGCXD-A3DNA1A
GWH09AGCXD-A3DNA4A
Product Code CB385015400
CB385015300
CB558009200
Power
Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9100 9100
Heating Capacity Btu/h / 10000
Cooling Power Input W 623 626
Heating Power Input W / 698
Cooling Power Current A 6.72 7.03
Heating Power Current A / 7.68
Rated Input W 1100 1580
Rated Cooling Current A 13.9 12.28
Rated Heating Current A / 16.59
Air Flow Volume CFM 371/324/294/265/241/224/194/129 353/324/294/265/235/206/194/129
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 14.6 14.55
COP (Btu/h)/W / 14.3
SEER 26.5 27
HSPF / 11.8
Application Area yd
2
53-57 53-57
Indoor
Unit
Model of indoor unit GWC09AGCXD-A3DNA1A/I
TW09HXP2A1AI
GWH09AGCXD-A3DNA4A/I
Indoor Unit Product Code CB385N15400
CB385N15300
CB558N09200
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ98×630 Φ98×630
Cooling Speed r/min 1350/1200/1100/1000/920/850/750/500 1300/1200/1100/1000/900/800/750/500
Heating Speed r/min / 1300/1200/1100/1000/900/850/800
Fan Motor Power Output W 15 15
Fan Motor RLA A 0.3 0.3
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 634×22.8×304.8 634×22.8×304.8
Swing Motor Model MP24HF / MP24AK / MP24BA MP24HF / MP24AK / MP24BA
Swing Motor Power Output W 1.5 / 1.5 / 1.5 1.5 / 1.5 / 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 41/37/34/31/29/27/24/22
Cooling: 40/37/34/31/29/26/24/22
Heating: 41/38/35/31/29/26/25
Sound Power Level dB (A) 51/47/44/41/39/37/34/32
Cooling: 50/47/44/41/39/36/34/32
Heating: 51/48/45/41/39/36/35
Dimension (WXHXD) inch 32 31/64 × 11 17/32 × 7 23/32 32 31/64 × 11 17/32 × 7 23/32
Dimension of Carton Box (LXWXH) inch 34 1/4 × 13 47/64 × 10 1/8 34 1/4 × 13 47/64 × 10 1/8
Dimension of Package (LXWXH) inch 34 29/64 × 14 3/8 × 10 35/64 34 29/64 × 14 3/8 × 10 35/64
Net Weight Ib 20.9 20.9
Gross Weight Ib 25.4 25.4
2. Specications
2.1 Specication Sheet
