Tosot TW09HXP2A1A User Manual

17
Technical Information
Service Manual
3. Outline Dimension Diagram
3.1 Indoor Unit
6 7/64*
W3W2W1
1 11/16
4 36/64*
Φ2 11/64
AGC
D
H
W
2 23/64*
Φ2 3/4
W3W2W1
1 11/16
6 57/64*
A
GE
1 11/16
Model W H D W1 W2 W3
AGC 32 31/64 11 17/32 7 23/32 4 29/64 21 11/32 6 11/16
AGD 38 21/32 12 1/4 8 45/64 4 53/64 27 55/64 5 63/64
AGE 42 21/64 13 7/64 9 11/16 7 7/32 27 55/64 7 1/4
* Recommending distances
Unit:inch
AGC
AGE
AGD
Φ2 11/64
7 1/64* 3 32/64*
1 37/64
1 37/6
4
W3W2W1
