Tosot TW09HXP2A1A User Manual

4
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWC09AGCXD-A3DNA1A/O
TW09HXP2A1AO
Outdoor Unit Product Code CB385W15400 CB385W15300
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO., LTD
ZHUHAI LANDA
COMPRESSOR CO., LTD
Compressor Model QXF-B103zH170E QXF-B103zH170E
Compressor Oil RB68EP RB68EP
Compressor Type Rotary Rotary
Compressor LRA. A 25 /
Compressor RLA A 12.5 12.5
Compressor Power Input W 800 800
Compressor Overload Protector / /
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature Range ºF -4~122 -4~122
Heating Operation Ambient Temperature Range ºF / -22~86
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ5 Φ7
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 816×22.8×514 802×38.1×528
Fan Motor Speed rpm 900 900
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 1295 1295
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ420 Φ420
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 51 52
Sound Power Level dB (A) 61 62
Dimension (WXHXD) inch 31 37/64 × 21 27/32 × 13 25/32 31 37/64 × 21 27/32 × 13 25/32
Dimension of Carton Box (LXWXH) inch 34 7/32 × 15 35/64 × 23 25/64 34 7/32 × 15 35/64 × 23 25/64
Dimension of Package (LXWXH) inch 34 21/64 × 15 43/64 × 24 13/32 34 21/64 × 15 43/64 × 24 13/32
Net Weight Ib 65 72.8
Gross Weight Ib 70.6 78.3
Refrigerant R410A R410A
Refrigerant Charge oz 30 35.3
Connection
Pipe
Connection Pipe Length ft 24.6 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max Distance Height ft 32.8 32.8
Max Distance Length ft 49.2 49.2
Note: The connection pipe applies metric diameter.
