Technical Information
Service Manual
Model GWC09AGCXB-D3DNA1A
GWH09AGCXD-D3DNA1A
GWH09AGCXD-D3DNA4A
Product Code CB385015500
CB385015600
CB558009400
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 9000 9100
Heating Capacity Btu/h / 10500
Cooling Power Input W 643 618
Heating Power Input W / 848
Cooling Power Current A 3.45 3
Heating Power Current A / 3.95
Rated Input W 1350 1343
Rated Cooling Current A 6.5 4.73
Rated Heating Current A / 6
Air Flow Volume CFM 353/324/294/265/235/206/194/129 353/324/294/265/235/177/159/106
Dehumidifying Volume Pint/h 1.69 1.69
EER (Btu/h)/W 14 14.72
COP (Btu/h)/W / 12.38
SEER 25 25.5
HSPF / 12
Application Area yd
2
53-16 53-57
Indoor
Unit
Model of indoor unit GWC09AGCXB-D3DNA1A/I
TW09HXP2A1DI
GWH09AGCXD-D3DNA4A/I
Indoor Unit Product Code CB385N15500
CB385N15600
CB558N09400
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Φ98×630 Φ98×630
Cooling Speed r/min 1300/1200/1100/1000/900/800/750/500 1300/1200/1100/1000/900/800/750/500
Heating Speed r/min / 1300/1200/1100/1000/900/850/800
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.22 0.22
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 634×22.8×304.8 634×22.8×304.8
Swing Motor Model MP24HF / MP24AK / MP24BA MP24HF / MP24AK / MP24BA
Swing Motor Power Output W 1.5 / 1.5 / 1.5 1.5 / 1.5 / 1.5
Fuse Current A 3.15 3.15
Sound Pressure Level dB (A) 41/39/32/26/25
Cooling: 40/37/35/32/29/26/25/22
Heating: 41/38/36/33/29/27/25
Sound Power Level dB (A) 51/49/42/36/35
Cooling: 50/47/45/42/39/36/35/32
Heating: 51/48/46/43/39/37/35
Dimension (WXHXD) inch 32 31/64 × 11 17/32 × 7 23/32 32 31/64 × 11 17/32 × 7 23/32
Dimension of Carton Box (LXWXH) inch 34 1/4 × 13 47/64 × 10 1/8 34 1/4 × 13 47/64 × 10 1/8
Dimension of Package (LXWXH) inch 34 29/64 × 14 3/8 × 10 35/64 34 29/64 × 14 3/8 × 10 35/64
Net Weight Ib 20.9 20.9
Gross Weight Ib 25.4 25.4
2. Specications
