Tosot TW09HXP2A1A User Manual

6
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWC09AGCXB-D3DNA1A/O
TW09HXP2A1DO
Outdoor Unit Product Code CB385W15500 CB385W15600
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD
ZHUHAI LANDA
COMPRESSOR CO., LTD
Compressor Model QXF-A082zC170 QXF-B103zH170E
Compressor Oil ZE-G;ES RB68GX or equivalent FW68DA
Compressor Type Rotary Rotary
Compressor LRA. A 15 /
Compressor RLA A 4.6 6.5
Compressor Power Input W 756.6 800
Compressor Overload Protector / /
Throttling Method Electron expansion valve Electron expansion valve
Set Temperature Range ºF 61~86 61~86
Cooling Operation Ambient Temperature Range ºF 0~115 -20~122
Heating Operation Ambient Temperature Range ºF / -22~86
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7 Φ7
Condenser Rows-n Gap mm 2-1.4 2-1.4
Condenser Coil Length (LXDXW) mm 700×38.1×528 761.5×38.1×528
Fan Motor Speed rpm 850 850
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume CFM 1148 1295
Fan Type Axial-ow Axial-ow
Fan Diameter mm Φ400 Φ420
Defrosting Method / Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 49 52
Sound Power Level dB (A) 59 63
Dimension (WXHXD) inch 28 13/16 × 21 27/32 × 12 63/64 31 37/64 × 21 27/32 × 13 25/32
Dimension of Carton Box (LXWXH) inch 31 9/64 × 14 11/16 × 23 15/64 34 7/32 × 15 35/64 × 23 25/64
Dimension of Package (LXWXH) inch 31 17/64 × 14 51/64 × 24 7/32 34 21/64 × 15 43/64 × 24 13/32
Net Weight Ib 57.3 70.6
Gross Weight Ib 62.8 76.1
Refrigerant R410A R410A
Refrigerant Charge oz 30 35.3
Connection
Pipe
Connection Pipe Length ft 24.6 24.6
Connection Pipe Gas Additional Charge oz/ft 0.2 0.2
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max Distance Height ft 39.4 32.8
Max Distance Length ft 65.6 49.2
Note: The connection pipe applies metric diameter.
2. Specications

Tosot TW09HXP2A1A Specifications

General

Brand	Tosot
Model	TW09HXP2A1A
Category	Air Conditioner
Language	English
