Technical Information
Service Manual
Model GWC12AGCXD-D3DNA1A
GWH12AGCXD-D3DNA1A
GWH12AGCXD-D3DNA4A
Product Code CB385016800
CB385016600
CB558009300
Power
Supply
Rated Voltage V~ 208/230 208/230
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity Btu/h 12000 12000
Heating Capacity Btu/h / 12000
Cooling Power Input W 961 961
Heating Power Input W / 923
Cooling Power Current A 4.3 4.3
Heating Power Current A / 4.1
Rated Input W 1400 1500
Rated Cooling Current A 6.3 6.3
Rated Heating Current A / 6.7
Air Flow Volume CFM 400/365/330/288/265/247/230/212 400/365/330/288/265/247/230/212
Dehumidifying Volume Pint/h 2.96 2.96
EER (Btu/h)/W 12.5 12.5
COP (Btu/h)/W / 13
SEER 24 24
HSPF / 11
Application Area yd
2
19-29 19-29
Indoor
Unit
Model of indoor unit GWC12AGCXD-D3DNA1A/I
TW12HXP2A1DI
GWH12AGCXD-D3DNA4A/I
Indoor Unit Product Code CB385N16800
CB385N16600
CB558N09300
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф98×630 Ф98×630
Cooling Speed r/min 1450/1200/1120/1050/980/920/750/500 1450/1200/1120/1050/980/920/750/500
Heating Speed r/min / 1450/1200/1140/1080/1020/960/900
Fan Motor Power Output W 15 15
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 634×22.8×304.8 634×22.8×304.8
Swing Motor Model MP24HF / MP24AK / MP24BA MP24HF / MP24AK / MP24BA
Swing Motor Power Output W 1.5 / 1.5 / 1.5 1.5 / 1.5 / 1.5
Fuse Current A 15 15
Sound Pressure Level dB (A) 43/38/36/34/32/30/27
Cooling: 43/38/36/34/32/30/27
Heating: 44/38/36/34/32/30/28
Sound Power Level dB (A) 53/48/46/44/42/40/37
Cooling: 53/48/46/44/42/40/37
Heating: 54/48/46/44/42/40/38
Dimension (WXHXD) inch 32 31/64 × 11 17/32 × 7 23/32 32 31/64 × 11 17/32 × 7 23/32
Dimension of Carton Box (LXWXH) inch 34 1/4 × 13 47/64 × 10 1/8 34 1/4 × 13 47/64 × 10 1/8
Dimension of Package (LXWXH) inch 34 29/64 × 14 3/8 × 10 35/64 34 29/64 × 14 3/8 × 10 35/64
Net Weight Ib 20.9 20.9
Gross Weight Ib 25.4 25.4
2. Specications

Tosot TW09HXP2A1A Specifications

General

Brand	Tosot
Model	TW09HXP2A1A
Category	Air Conditioner
Language	English
