10. Exploded View and Parts List
NO. Description
1 Front Panel
2 Guide Louver (upper)
3 Guide Louver (lower)
4 Screw Cover
5 Front Case
6 Filter Sub-Assy
7 Helicoid Tongue
8 Air Louver(left)
9 Left Axile Bush
10 Rear Case assy
11 Ring of Bearing
12 O-Gasket sub-assy of Bearing
13 Evaporator Support
14 Wall Mounting Frame
15 Evaporator Assy
16 Cross Flow Fan
17 Motor Press Plate
18 Fan Motor
19 Connecting pipe clamp
NO. Description
20 Drainage Hose
21 Stepping Motor
22 Stepping Motor
23 Crank
24 Air Louver(auto)
25 Sweeping connecting rod
26 Stepping Motor
27 Air Louver(right)
28 Main Board
29 Electric Box Assy
30 Terminal Board
31 Electric Box Cover
32 Display Board
33 Power Cord
34 Connecting Cable
35 Connecting Cable
36 Remote Controller
37 Detecting plate (WiFi)
Some models may not contain some parts, please refer to the actual product.
