NO. Description
1 Front Panel
2 Front Case Assy
3 Screw Cover
4 Front Case
5 Plug Pin
6 Guide Louver Sub-assy 1
7 Guide Louver Sub-assy 2
8 Sweeping Connecting Rod
9 Air Louver(Automatic)
10 Helicoid Tongue
11 Left Axile Bush
12 Rear Case
13 Drainage Hose
14 Cross Flow Fan
15 O-Gasket sub-assy of Bearing
16 Ring of Bearing
17 Evaporator Support
18 Evaporator Assy
19 Wall Mounting Frame
20 Motor Press Plate
21 Fan Motor
22 Plasmacluster Ion
NO. Description
23 Connecting pipe clamp
24 Rubber Plug (Water Tray)
25 Crank
26 Stepping Motor
27 Stepping Motor
28 Stepping Motor
29 Sweep Blade
30 Air Louver(Automatic)
31 Electric Box
32 Display Board
33 Main Board
34 Jumper
35 Supporter
36 Terminal Board
37 Cable Clamp
38 Electric Box Assy
39 Electric Box Cover
40 Connecting Cable
41 Power Cord
42 Temperature Sensor
43 Remote Controller
Some models may not contain some parts, please refer to the actual product.
10. Exploded View and Parts List
