10. Exploded View and Parts List
NO. Description
1 Coping
2 Condenser Left Border Plate
3 Inhalation Tube
4 Sponge (Condenser)
5 Tempreture Sensor Support
6 Condenser Assy
7 Tempreture Sensor Sleeving
8 Sensor Insert B
9 Right Side Plate Assy
10 Earthing Plate Sub-assy
11 Wire Clamp
12 Electric Expansion Valve Sub-Assy
13 Electric Expand Valve Fitting
14 Handle
15 Silencer
16 Cut-off valve 3/8(N) or 1/2(N)
17 Furcate Filter
18 Cut-off valve 1/4(N)
19 Valve Support
20 Discharge Tube
NO. Description
21 Compressor and Fittings
22 Chassis Sub-assy
23 Motor Support
24 Brushless DC Motor
25 Axial Flow Fan
26 Cabinet
27 Front Grill
28 Drainage Joint (ODU)
29 Left Side Plate Assy
30 Clapboard
31 Reactor
32 Electric Box Assy
33 Electric Box
34 Main Board
35 Electric Box Cover
36 Terminal Board
37 Temperature Sensor
38 Raidator
39 Valve Cover
Some models may not contain some parts, please refer to the actual product.
