88
Installation and Maintenance
Service Manual
10. Exploded View and Parts List
NO. Description
1 Front Grill
2 Cabinet
3 Axial Flow Fan
4 Chassis Sub-assy
5 Compressor and ttings
6 Electron expansion valve
7 Electric Expand Valve Fitting
8 Right Side Plate Assy
9 Valve Support Sub-Assy
10 Cut-off Valve
11 Cut-off Valve
12 Valve Cover
13 Handle
14 Terminal Board
NO. Description
15 4-way valve Assy
16 Condenser Assy
17 Clapboard Assy
18 Motor Support Sub-Assy
19 Brushless DC Motor
20 Top Cover Assy
21 Left Side Plate
22 Condenser Left Border Plate
23 Electric Box Assy
24 Radiator
25 Electric Box
26 Main Board
27 Electric Box Cover
Some models may not contain some parts, please refer to the actual product.
