TOTALIFT Battery Chargers User's Manual
__________________________________________________________________________________________________________________________________________________
Page 6/19
3. INSTALLATION OF THE CHARGER
Conditions of use:
• Operating temperature: 5°C to 45°C
• Storage temperature: -20°C to 60°C
• Relative humidity: less than 75%
AC INPUT CONNECTION
The charger must be connected to the AC input using an adequate cable and plug, with
disconnect switch and fuses.
The AC input wires have to be connected to the TERMINAL BLOCKS FOR AC INPUT WIRES,
that are located on the internal panel, just under the AC input contactor.
Make sure to tighten the terminal block screws with the proper torque, and pull each wire
separately in order to verify that they are mounted properly.
AC INPUT VOLTAGE SETTINGS
CAUTION!
Risk of electrical shock!
The charger can be installed by qualified personnel only.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
Don't use the unit in presence of flammable gas, because it can generate sparks.
ATTENTION!
Make sure that the unit's maximum input power (reported on the data label) is available from
your power supply, and verify that the unit's operating voltage is correct.
Allow adequate air circulation to prevent internal heat buildup.
Don't place the unit near heat sources such as radiators or air ducts, or in a place subject to
direct sunlight, excessive dust, mechanical vibration or shock.
