TOTALIFT Battery Chargers User's Manual
__________________________________________________________________________________________________________________________________________________
Page 12/19
The other dip-switches 1 and 4 are used to set the daily and/or the weekly equalization.
BATTERY CONNECTION – VOLTAGE CHECK AND AUTOSTART
Connect the battery to the charger, using an adequate plug.
When the battery is correctly connected, the display turns on and shows the battery voltage.
If the battery voltage is lower than the minimum threshold of 1, 62 V/cell, the charger doesn't
start, and the display will show the error message “Voltage Low”:
ATTENTION!
TOTALIFT OPPORTUNITY chargers are programmed to execute a complete cycle of charge
automatically, however it’s recommended to survey the operations when the battery remains
connected to the charger for more than 12 hours (example: week-ends).
