User’s Guide | TOTEM 10 - TOTEM 20
12 of 30
Coolant max flow rate l/h 4000
Max pressure drop with max flow rate bar 0.5
Coolant temp. range °C 30 - 75
Hydraulic In/Out threading/coupling size Inch 1"
Installation environment temp. range °C -20°C +60
Mechanical Design B3/B5 (foot and flange mounting)
Direction of axis horizontal
Terminal box position
Effiiency 92.7 (Efficiency class: IE3)
Power supply - Voltage - Frequency Three-phase- 400V - 50 Hz
Insulation/Duty class H/S1 – continuous duty
Rated power factor >0.81
Winding connection Delta/Wye 400/690 V
Height of axis mm 160
Shaft diameter mm 42
Length mm 620 (shaft excluded)
Shaft length mm 110
Compliance with standards:
2006/42/EC Machinery Directive;
2006/95/EC Low Voltage Directive;
2004/108/EC EMC Directive;
IEC EN 60034;
1997/23/EC Directive.
- Heat Recovery System
The TOTEM® unit is equipped with a high performance in-built heat exchange
system that can recover heat energy from the gen set, the engine water and oil
circuits, and exhaust fumes. The system does not include any heat dissipator device,
therefore, it is only activated following heat demand.
Heat is recovered by means of the following equipment:
Asynchronous generator: the heat recovery system is incorporated in
the gen set canopy. Please see the generator features section.
Engine Oil: AISI 316L stainless steel water/oil brazed plate heat
exchanger
Engine water: AISI 304 stainless steel brazed plate heat exchanger
Exhaust gases: AISI 304 stainless steel water/fumes tube bundle heat
exchanger.
The engine water circuit is governed by a high-efficiency circulator pump having the
following technical features:
Power supply V 230
Frequency Hz 50
Max. current A < 2
