7.9 Nose Wheel Cradle Replacement
There are several reasons why a nose wheel mount needs to be replaced. One reason may
be a defect, or a change of the aircraft, which has a dierent nose wheel size. In order to
remove the mount and insert a new one, only 8 bolts have to be removed, which are marked
in the following picture.
The installation of a new nose wheel mount is performed in reverse order. This principle is
the same for all dierent types of mounts.
Tip: We recommend a 17mm wrench (M10) for removing the mount.
Tip: For replacing the nose wheel mount, we recommend that a second person
assists you.
Attachment of the TF3 nose wheel mount
