AIR CLEANER
SPECIFICATIONS
COMPONENTS
Single (STD) Double (OPT)
Type Cyclone type
Size 6-inch
Intake type Fresh air introduction type
Filtering area
cm
2
(in
2
)
14000 (2170)
Outer 14000 (2170)
Inner 570 (88.4)
Others With evacuator valve
1703
Engine
Section 1
1-15b
8FGCU15,18,SU20
