167
3-2. Open
ing, closin
g and loc
king the
doors
3
Operati
on of eac
h component
C-HR_OM_Europe_OM10528E
■
If the back do
or opener is inoperative
The back door can be operated from the inside.
Using
a screw
driver
, remove th
e cove
r
.
T
o protect the cover
, place a rag
between the flathead screwdriver and
the cover as shown in the illustration.
Loosen the screw
.
T
urn t
he cove
r
.
Move t
he le
ver
.
1
2
3
4
166
168
