Toyota Corolla E12-A - Final Panel Cuts and Fitting

05-04
Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 17
27. Cut the marked area using a ruler as
shown.
Fig. 27
Ruler
3
28. Fit the panel on the lower cluster
panel using clips .
: Clip (2x)
12
12
3
11
Fig. 28
3
3
12
12
11
11
