Toyota Corolla E12-A - SUBWOOFER INSTALLATION; Subwoofer Placement and Bracket Fitting

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 30
05-04
6. SUBWOOFER INSTALLATION
Fig. 59
24
24
Make sure that the connector side of
the subwoofer is directed towards
the centre of the vehicle.
24
CAUTION
1. The standard installation position of
the subwoofer is under the driver’s
seat. If it is not feasible, it can be
installed under the passenger’s seat.
24
Fig. 60
2.
a) Remove the screws from the sub-
woofer .
b) Fit the attachment brackets (2x) to
the subwoofer using bolts .
: Bolt with washer (4x)
c) Attach the cushion tape (2x)
(10mm) to the subwoofer .
24
28
27
27
24
26
24
25
25
26
28
27
24
