Toyota Corolla E12-A - Tweeter Mounting on A-Pillar

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 26
05-04
4. Cut out the template (see fitting kit)
and put it on the A-pillar cover.
Drill 2 holes of 7 mm.
Drill a hole of 32 mm.
Fig. 49
5. Cut out the necessary foam and ribs at
the back of the A-pillar cover .
23
Fig. 50
23
6. Install the tweeter on the A-pillar
cover .
: Screw (2x)
Mount the A-pillar cover on the
vehicle.
23
22
23
21
Fig. 51
23
21
22
