Toyota Corolla E12-D - Carpet Preparation for Installation

Corolla (E12-A + E12-D) TOYOTA GENUINE AUDIO
Corolla (RHD) - 31
05-04
4. Cut the tape (10 pieces).
29
Fig. 62
3. Cut the carpet as shown in the illustration.
Fig. 61
29
25
20mm
10mm
115mm
130mm
20mm
THE STANDARD INSTALLATION POSITION OF THE SUBWOOFER IS UNDER THE DRIVER’S SEAT. IF
IT IS NOT FEASIBLE, IT CAN BE INSTALLED UNDER THE PASSENGER’S SEAT.
24
Duct
