209
4-1. Before driving
4
Driving
HIGHLANDER_U (OM0E017U)
Use the correct trailer ball for your application.
Trailer ball load rating
Matches or exceeds the gross
trailer weight rating of the trailer.
Ball diameter
Matches the size of the trailer cou-
pler. Most couplers are stamped
with the required trailer ball size.
Shank length
Protrudes beyond the bottom of the lock washer and nut by at least 2
threads.
Shank diameter
Matches the ball mount hole diameter size.
Weight carrying ball position:
49.73 in. (1263.1 mm)
Selecting trailer ball
1
2
Trailer class Typical trailer ball size
IV
2 5/16 in.
II and III
2 in.
I
1 7/8 in.
Position for towing hitch ball
3
4
1
