2-1. Instrument cluster
Vehicle status information and indicators
*
: If equipped
Illustrations used in this text are intended as examples, and may differ from the
image that is actually displayed by the head-up display.
Vehicle speed display area
RSA (Road Sign Assist) display area (P.2 16 )
Shift position display (P.158)
Message display area (P. 85 )
The following pop-up displays will be displayed in certain situations:
• Warning/message
• Hands-free system status
• Audio system operation status
Navigation system-linked display area (if equipped) (P. 84 )
Displays the following items, which are linked to the navigation system:
• Route guidance to destination
• Street name
• Compass (heading-up display)
Head-up display
*
The head-up display is linked to the meters and navigation system
(if equipped) and projects a variety of information in front of the
driver, such as the current vehicle speed and route guidance to a set
destination.
System components
