TOYOTA MY22 RAV4 2022 - DASHCAM (Digital Video Recorder)
Procedure
(4) Pull the remaining slack harness back
into the headliner / map light console
area as per the image. (Fig. 8-5)
9. Route Dashcam Harness through the
Headliner
(a) From the driver’s side of the windshield,
locate the notch in the front edge of the
headliner if available (Fig. 9-1)
(b) Route the Dash Cam pigtail through the
notch or similar area, and into the
headliner. Take care not to crease the
headliner in the process. (Fig. 9-2)
(c) Feed the Dashcam harness through to
the open Map Light Console area.
(Fig. 9-3)
Fig. 8-5
Fig. 9-1
Fig. 9-2
To Next Page
