Instruction
Form：DP5-005 Revised：05 14
◇Status LEDs function
Name Color Contents
RUN Green
Wireless ST start status
On: Starting （Just after power is supplied）
Blink: Running （Blink 2 sec approximately）
Off: Device power is OFF.
COLLISION Yellow
Ethernet collision detection
On: Data collision
Off: Normal
* With RJ-45 connector （COLLISION）
RECEIVE/LINK Green
Ethernet link
On: Connection status is good.
Blink: Data communication
Off: Connection is not performed or confirmed.
* With RJ-45 connector（RECEIVE/LINK）
MODE Green
Operation status
On: Inspection mode
Blink: Parameter write mode
Off: Search mode
COM PORT Orange
Wireless ST diag communication status
On: Communicating
Off: Without communication
ANTENNA Green
Antenna
On: ANTENNA 1 is used
Off: ANTENNA 2 is used
RF LINK Green
Communication status between wireless
terminals
On: Communicating
Off: Without communication
PRG Green
Program rewriting mode
On: Program rewriting mode
Off: Normal operation mode
◇Status (7 segmentLED) function
Display frequency set for Wireless module.
[----] is displayed when wireless communication is stopped.
