Toyota TM4875A - How to Operate

Instruction
Form：DP5-005 Revised：05 15
《No.2 Wireless terminal》
◇Function name
No. Name Purpose
①
DLC3 connector
Vehicle connection
②
Disconnection prevention lock Wireless terminals disconnection
prevention
③
Status LED Wireless terminals status display
（Refer to followings）
④
FLASH connector For cradle connection
50.0 [mm]
1
24.0 [mm]
4
2
67.4 [mm]
83.4 [mm]
3
