Instruction
Form：DP5-005 Revised：05 31
Parameter for wireless (For details, refer to [6.Parameter explanation].)
Item Default setting Setting range
Initial Mode Radio frequency 2453MHz (Ch52)
2402MHz(Ch1)～2480MHz(Ch79)
Wireless ID 52
0～255
Wireless output -1dBm
-21dBm～+5dBm
Inspection
Mode
Radio frequency 2456MHz (Ch55)
2402MHz(Ch1)～2480MHz(Ch79)
Wireless ID 0
0～255
Wireless output +2dBm
-21dBm～+5dBm
Wireless output
(For wireless terminal)
+2dBm
-21dBm～+5dBm
Parameter
Write Wait
Mode
Radio frequency 2480MHz(Ch79)
2402MHz(Ch1)～2480MHz(Ch79)
Wireless ID 0
0～255
Wireless output -1dBm
-21dBm～+5dBm
Parameter
Write Mode
Radio frequency 2456MHz(Ch55)
2402MHz(Ch1)～2480MHz(Ch79)
Wireless ID 55
0～255
Wireless output +2dBm
-21dBm～+5dBm
Wireless output
(For wireless terminal)
+2dBm
-21dBm～+5dBm
All Mode Effective/Disable setting ON ON(Effective)/OFF(Disable)
A
ntenna change judgment
interval
20msec
5msec～65535msec
Antenna change judgment
Wireless receive stop rate
50.00%
0.01%～100%
Single direction
communication
Number of antenna
change judgment
1 time 1 time – 65535 times
Mode shift parameter (Refer to [6.Parameter explanation])
Item Default setting Setting range
Mode processing timeout Initial mode shift
process
1000msec
100msec～65535msec
Inspection mode shift
process
Diag communication
process
BodyNo delete process
Parameter write mode
shift process
