TP-Link AC1900 User Manual

7
Chapter 2 Connect the Hardware
2. 1. Position Your Router
• The product should not be located in a place where it will be exposed to moisture or
excessive heat.
• Place the router in a location where it can be connected to multiple devices as well as
to a power source.
• Make sure the cables and power cord are safely placed out of the way so they do not
create a tripping hazard.
• The router can be placed on a shelf or desktop.
• Keep the router away from devices with strong electromagnetic reference, such as
Bluetooth devices, cordless phones and microwaves.
2. 2. Connect Your Router
Follow the steps below to connect your router.
If your internet connection is through an Ethernet cable directly from the wall instead
of through a DSL / Cable / Satellite modem, connect the Ethernet cable to the router’s
Internet port, and then follow Step 1, 5 and 6 to complete the hardware connection.
Modem
Power adapter
Router
Power adapter
5
Internet
2
4
3
1
1. Install the antennas.

TP-Link AC1900 Specifications

General

Model	RE580D
Beamforming	Yes
Frequency Bands	2.4 GHz, 5 GHz
Wireless Standards	IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Wireless Security	WPA/WPA2
Button	WPS Button, Reset Button
Maximum Speed	1900Mbps (600Mbps at 2.4GHz + 1300Mbps at 5GHz)
