TP-Link AC600 User Manual

12
Function
Panel
Definition
Reset Press and hold 2~5 seconds to do system reboot,
Press and hold > 5 seconds till SYS LED is blinking to
do restore all settings to factory defaults
WPS Press and hold WPS button for 3 seconds till WLAN
LED is On Solid to start WPS H/W PBC.
5G band Switch to 5G, WiFi of Travel Router will run on 5G
band, 11a/n/ac mode.
2.4G band Switch to 2.4G, WiFi of Travel Router will run on 2.4G
band, 11b/g/n mode.
USB Cable
and Connector
For Travel router power supply only.
Ethernet Port Travel Router mode: WAN Port
Wireless ISP mode: LAN Port

TP-Link AC600 Specifications

General

Interface	USB 2.0
Antenna	Internal
Model	Archer T2U
Wireless Standard	IEEE 802.11ac
Frequency	2.4GHz, 5GHz
Security	WEP, WPA, WPA2
Data Rate	5 GHz: Up to 433 Mbps, 2.4 GHz: Up to 150 Mbps
Operating Systems Supported	Windows 11/10/8.1/8/7/XP, Mac OS X 10.9-10.13
