4
Chapter 1
• Support simultaneous 2.4GHz and 5GHz connections
• Multiple detachable external antennas and high power amplifiers provide stable
signals and optimal wireless coverage
• Up to 4 SSIDs and VLAN support
• Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption
security
• Supports MAC filter, throughput monitor
• Easy one-touch WPA wireless security encryption with the WPS button
• Supports firmware upgrade and Web management
• Supports system log and Traffic Statistics
1. 3. Panel Layout
1. 3. 1. Top View
The AP device’s LEDs are located on the top panel. You can check the AP device’s
working status by following the LED Explanation table (view from left to right).
LED Explanation
Name Status Indication
(Power)
On System initialization completes.
Blinking
System initialization or firmware upgrade is in process. Do not
disconnect or power off the AP device.
Off
Power is off. Please ensure that the power adapter is connected
correctly.
