12
Chapter 2
Connect to the Internet
6. Follow the Quick Setup to set up the internet connection.
7. Enjoy! Connect to the wireless network by using the SSID (network name) and
password of the router.
2. 2. 3. Range Extender Mode
This mode boosts your home wireless coverage.
1. Connect the power adapter to the router.
2. Connect a computer to the router via an Ethernet cable or wirelessly by using the
SSID (wireless name) and password printed on the bottom label of the router.
3. Enter http://tplinkwifi.net in the address bar of a web browser. Create a password
to log in.
4. Click Change Mode in the top right corner and select Range Extender Mode. Wait
for the router to reboot.
5. Follow the Quick Setup to set up the internet connection.
6. Relocate: Place the router between your host router and the Wi-Fi dead zone. The
location you choose must be within the range of your existing host network.
Extended NetworkHost Network
DevicesHost Router Router
To Next Page
