TP-Link Auranet Series - Page 51

Figure 6-7 LAN Traffic
Rx/Tx Packets:
Displays the total amount of packets received/sent on the LAN port.
Rx/Tx Bytes:
Displays the total amount of data (in bytes) received/sent on the LAN port.
Rx/Tx Dropped
Packets:
Displays the total amount of dropped packets received/sent on the LAN
port.
Rx/Tx Errors:
Displays the total amount of error packets received/sent on the LAN port.
 Radio Traffic
Click Radio Traffic and you can monitor the data transmission status of the wireless network.
Figure 6-8 Radio Traffic
2.4GHz/5GHz:
Choose one band to show the information about radio traffic.
Rx/Tx Packets:
Displays the total amount of packets received/sent by the wireless network.
Rx/Tx Bytes:
Displays the total amount of data (in bytes) received/sent by the wireless
network.
Rx/Tx Dropped
Packets:
Displays the total amount of dropped packets received/sent by the wireless
network.
Rx/Tx Errors:
Displays the total amount of error packets received/sent by the wireless
network.
40
