Lightning Protection
Signal lightning arrester is used to protect RJ45 ports of the device from lightning. When
cabling outdoors, please install a signal lightning arrester before connecting the cable to the
device.
When purchasing or using a signal lightning arrester, please observe the following rules:
»
The port rate of the signal lightning arrester should match the rate of the desired port
on the device. If it is not matched, this signal lighting arrester will not work. Purchase a
standard lightning arrester.
»
Install signal lightning arrester near the protected device and connect it to the ground via
a shorter ground cable.
Figure 4 Use Lightning Arrester
Ethernet CableEquipotential Bonding CableGrounding Terminal
Signal Lightning Arrester Device
Note:
Signal lightning arrester is not provided with our product. If needed, please self purchase it.
