TP-Link m7310 User Manual

8
Chapter 2
Set Up Internet Connection
2. 1. Install the Hardware
2. 1. 1. Installation
1. Remove the cover and the battery.
2. Slide and lift up the SIM card slot cover and insert the SIM card.
SIM
Note:
• A nano SIM card must be converted using the provided SIM card tray.
• The SIM card is not provided by TP-Link.
3. (Optional) Slide and lift up the SD card slot cover and insert a micro SD card.
The inserted SD card can be used for storage and media sharing.
Note:
• To learn how to store and share files via the SD card, please refer to Share Files on SD Card.
• The SD card is not provided by TP-Link.
4. Fit the battery into the slot.

TP-Link m7310 Specifications

General

Wi-Fi	Yes
WLAN data transfer rates supported	150 Mbit/s
Device type	Cellular wireless network equipment
Certification	CE, RoHS
Product color	Black, Grey
Compatible memory cards	MicroSD (TransFlash)
Data network	EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Number of simultaneous SIM cards	1
Battery voltage	5 V
Battery capacity	2000 mAh
Display diagonal	1.44 \
Security algorithms	WPA-PSK, WPA2-PSK
Operating frequency	2.4, 5 MHz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Market positioning	Portable

Weight and Dimensions

Depth	60.5 mm
Width	98.5 mm
Height	16 mm
