Omada Smart Switch
01 Introduction
Chapter 1 Introduction
1.1 Product Overview
Designed for workgroups and departments, TP-Link Omada Smart Switch provides wire-speed
performance and abundant L2 management features. It provides a variety of service features and
multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions for
a variable scale of networks. QoS and IGMP snooping/filtering optimize voice and video application.
Link aggregation increases aggregated bandwidth, optimizing the transport of business critical
data. SNMP, RMON, WEB and CLI Login bring abundant management policies. TP-Link Omada Smart
Switch integrates multiple functions with excellent performance, and is friendly to manage, which
can fully meet the need of the users demanding higher networking performance.
SG2210MP/SG2218P/SG2428P/SL2428P is also a Power Sourcing Equipment (PSE*). Some of the
RJ45 ports on the switch support Power over Ethernet (PoE*) function, which can automatically
detect and supply power to those powered devices (PDs*) complying with IEEE 802.3af and IEEE
802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: a technology describes a system to transmit electrical power, along with data, to remote
devices over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network
cameras, wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2 Appearance
■
Front Panel
The front panel of SG2218 is shown as the following figure.
Figure 1-1 Front Panel of SG2218
LEDs Reset 10/100/1000 Mbps RJ45 Port SFP Slot
The front panel of SG2210MP is shown as the following figure.
Figure 1-2 Front Panel of SG2210MP
LEDs
LED Mode
Switch Button
Reset
10/100/1000 Mbps
RJ45 Port and PoE Port
SFP Slot
