Omada L2+/Stackable Lite L3 Managed Switch
08 Introduction
LED Indication
Port 1–24
Left LED
(Only for SX3832)
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 5 Gbps, but no activity.
Yellow Flashing: Running at 5 Gbps and transmitting or receiving data.
Off (Both Left and Right): No device is linked to the corresponding port.
Port 1–24
Left LED
(Only for SX3832MPP)
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 100 M/1000 M/2.5 G/5 Gbps, but no activity.
Yellow Flashing: Running at 100 M/1000 M/2.5 G/5 Gbps and transmitting or
receiving data.
Off: No device is linked to the corresponding port.
Port 1–24
Right LED
(Only for SX3832)
Green On: Running at 2.5 Gbps, but no activity.
Green Flashing: Running at 2.5 Gbps and transmitting or receiving data.
Yellow On: Running at 100/1000 Mbps, but no activity.
Yellow Flashing: Running at 100/1000 Mbps and transmitting or receiving data.
Off (Both Left and Right): No device is linked to the corresponding port.
Port 1–24
Right LED
(Only for SX3832MPP)
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum
power.
Yellow On: Overload or short circuit is detected.
Yellow Flashing: Power-on self-test failed.
Off: Not providing PoE power on the port.
SFP+
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
For SG3210X-M2
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS
Flashing: The switch works properly.
On or Off: The switch works improperly.
2.5G
On: Running at 2.5 Gbps, but no activity.
Flashing: Running at 2.5 Gbps and transmitting or receiving data.
Off: Running at 1000/100 Mbps or no device is linked to the corresponding port.
