Omada L2+/Stackable Lite L3 Managed Switch
02 Introduction
The front panel of SX3032F is shown as the following figure.
SFP+ Slot
LED
Console Port
(RJ45/USB)
LED
The front panel of SX3832 is shown as the following figure.
SFP+ Slot
LED
Console Port
(RJ45/USB Type C)
LED
10G
RJ45 Port
The front panel of SX3832MPP is shown as the following figure.
SFP+ Slot
LED
LED
10G
RJ45 Port
Console Port
(RJ45/USB Type C)
The front panel of SG3210 is shown as the following figure.
2
1
4
3
6
5
8
7
10
9
PWR
SYS
10/100/1000M SFP
LED Console Port
(RJ45/USB)
1G RJ45 Port SFP Slot
The front panel of SG3210X-M2 is shown as the following figure.
Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
LED
LED
The front panel of SG3210XHP-M2 is shown as the following figure.
LED Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
