Omada L2+/Stackable Lite L3 Managed Switch
03Introduction
The front panel of SG3218XP-M2 is shown as the following figure.
LED
Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
The front panel of SG3428 is shown as the following figure.
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP Slot
The front panel of SG3428MP is shown as the following figure.
LED Console Port
(RJ45/USB)
1G
RJ45 Port
SFP Slot
The front panel of SG3428X is shown as the following figure.
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP+ Slot
The front panel of SG3428XF is shown as the following figure.
LED Console Port
(USB/RJ45)
1G
RJ45 Port
SFP+ SlotSFP Slot
25 2721T 23T1 3 5 7 9 11 13 15 17 19 21 23
26 28
22T 24T2 4 6 8 10 12 14 16 22 2418 20
FAN
SYS
PWR1
PWR2
4
3
1
2
8
7
5
6
12
11
9
10
16
15
13
14
20
19
17
18
24
23
21
22
28
27
25
26
Console(RJ45)
Console(USB)
Port 1-24
1000Mbps
100Mbps
Activity
Port 25-28
10Gbps
1Gbps
Activity
The front panel of SG3428XMP is shown as the following figure.
LED
Console Port
(RJ45/USB)
1G
RJ45 Port
SFP+ Slot
