Omada L2+/Stackable Lite L3 Managed Switch
04 Introduction
The front panel of SG3428XMPP is shown as the following figure.
LED
1G
RJ45 Port
Console Port
(RJ45/USB)
SFP+ Slot
The front panel of SG3428X-M2 is shown as the following figure.
LED Console Port
(USB/RJ45)
2.5G
RJ45 Port
SFP+ Slot
The front panel of SG3428XPP-M2 is shown as the following figure.
LED Console Port
(RJ45/USB)
2.5G
RJ45 Port
SFP+ Slot
The front panel of SG3452 is shown as the following figure.
F
LED
1G RJ45 Port
SFP Slot
Console Port
(USB/RJ45)
The front panel of SG3452P is shown as the following figure.
F
LED
1G RJ45 Port
SFP Slot
Console Port
(RJ45/USB)
Speed
PWR
SYS
PoE Max
FAN
PoE
Console(USB)Console(RJ45)
PoE
Delivering Power
Over Budget
Fault
Speed
activity1000Mbps
10/100Mbps
The front panel of SG3452X is shown as the following figure.
LED
1G RJ45 Port
SFP+ Slot
Console Port
(RJ45/USB)
ConsoleConsole(USB)
1000Mbps
10/100Mbps
SFP+
activity
10Gbps
1Gbps
