TP-Link RE705X User Manual

7
Chapter 2
Set Up Internet Connection
2. 1. Power On the Extender
Plug the extender into an electrical outlet next to your router, and then wait until the
Power LED turns solid on.
Note: For safety, only plug the extender in upright direction as shown below.
Solid On
2. 2. Set Up the Extender
There are three ways to set up the extender: via the TP-Link Tether app, via a web
browser, or via the WPS button.
2. 2. 1. Method 1: Via the TP-Link Tether App
1. Launch the Apple App Store or Google Play Store and search TP-Link Tether or simply
scan the QR code to download and install the app.
OR
2. Launch the Tether app and log in with your TP-Link ID.
Note: If you don’t have a TP-Link ID, create one first.
3. Tap the + icon on the upper-right corner and select Range Extender.

TP-Link RE705X Specifications

General

Antenna type	External
Product type	Mesh router
Reset button	Yes
Product color	White
Antennas quantity	2
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Security algorithms	WEP, WPA, WPA2, WPA3
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11g
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Ethernet LAN (RJ-45) ports	1
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	12.6 W
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth	46 mm
Width	97 mm
Height	158 mm
Package depth	125 mm
Package width	202 mm
Package weight	430 g
